13 True Horizon
13.1
Introduction
Sometimes the composition of the frame requires manually adjusted horizon
and an easy way to get the Roll axis back to the physical Zero position.
This is especially important when using wheels for example, or for fast movements.
The True Horizon function allows to move the head back into the Zero position !
just by touching the assigned button B4.
13.2
Precondition
NOTE
The used controller needs to be: !
Wheels, Joystick, internal Zoom Rocker !
or Master Grip Zoom rocker.
NOTE
The Roll Axis needs to be in Speed Mode.
13.3
Usage
By using one of the listed controllers, the horizon can be adapted to the desired framing.
That means of course that the horizon in the frame may be offset to the physical !
Zero position.
To reach the physical Zero position, press button B4.
!
!
!
NOTE
When this special feature is not needed anymore, !
set the Roll axis back to Position Mode.
"
