21 FIZ!
Due that the SRH-3 remote control panel and head, supported LBUSe, controllers like
the Master Grips, the optional internal Focus wheel and Zoom rocker and cforce lens
motors can be used.
Adding the LCUBE 2-A, allows to use a selection of broadcast cameras and lenses.!
!
NOTE
Only supported LBUS products can be connected to the SRH-3 Remote Head.!
!
21.1
FIZ Configurations:!
!
!
Master Grips:!
!
!
!
!
!
!
Internal Focus & Zoom controllers:!
!
!
!
!
WCU-4 wireless:
Broadcast Internal Focus & Zoom controllers:
!
Broadcast Master Grips:
FIZ
Focus
Zoom
Iris
Wired
Wireless
Focus
Zoom
Iris
Wired
Wireless
Wired
Wireless
Focus
Zoom
Iris
from
RCP
Wired
Wireless
( )
( )
Focus
Zoom
Focus / Zoom / Iris
Or
Iris
from
RCP
Wired
Wireless
( )
( )
Focus
Zoom
Focus / Zoom / Iris
Or
Focus
Zoom
