23 Mounting Accessories
!
To mount one or two monitors and a WVR-1 receiver to the back of the !
SRH-3 Remote Control you need following parts:
•
one or two RMB-2 K2.66250.0 mounted at the back of the Remote Control
•
one 19mm rod, like the K2.0014954!
For the monitor and receiver following brackets are available:!
• Monitor Adapter for Transvideo K2.0014831
• Monitor Adapter for Small HD K2.0014832
• Adjustable Monitor Mount AMM-1 K2.0014829
• Rod Mounting Bracket RMB-5 K2.0014827
!
!
To power the monitor with 4pin XLR, the Monitor Power, 12V, Lemo 0B 2pin K2.0010546
is needed and to power the K2.0010546, the Cable RS - RS/PWR IN (0.5m/1.6ft)
K2.0001637 is needed.
NOTE
If users would like a monitor, and the WVR-1 receiver is powered through the SRH-3
remote control, the remote control itself must be powered through the 4pin XLR power
in with 12V from an external battery.!
!
12V Bat Pwr Cable D-Tab 4p XLR K2.0020467
A
Support Systems
Price List - EU 05/2018
Ident Nr Product Description/Weight & Dimensions Price
Mounting Hardware
2800 Mounting Hardware
In the chapter mounting hardware a lot of adapters, extensions and other useful bracketry is listed.
Shoulder Belt AdaptersK2.0001223 €34
17 gr
Offers compatibility with standard ENG shoulder belts.
Rod Mounting Bracket RMB-2 SetK0.60209.0 €180
KK.0005807
The Rod Mounting Bracket RMB-2 can be attached to any ARRI 3/8-16 inch interface
and holds a standard 19 mm rod (15 mm rod with a reduction insert).
includes:
K2.66250.0 1x Rod Mounting Bracket RMB-2
K2.66255.0 1x 15mm Reduction Insert
Basic Set 15mm Reduction InsertK0.60211.0 €130
KK.0005809
The 15 mm reduction insert can be fitted to any 19 mm rod mount to allow
compatibility with 15 mm rods.
includes:
K2.66255.0 5x 15mm Reduction Insert
Pro Set 15mm Reduction InsertK0.60210.0 €230
KK.0005808
The 15 mm reduction insert can be fitted to any 19 mm rod mount to allow
compatibility with 15 mm rods.
includes:
K2.66255.0 10x 15mm Reduction Insert
The 15 mm reducing insert can be fitted to any 19 mm rod mount to allow
compatibility with 15 mm rods.
15mm Reduction InsertK2.66255.0 €27
The 15 mm reducing insert can be fitted to any 19 mm rod mount to allow
compatibility with 15 mm rods.
