Installation
IPC1100 Advanced IP Client Video Set-top • Installation and Operations Manual
36
365-095-24769 x.1 10/13
Setting Description
BLUE, YELLOW, MAGENTA, or CYAN.
Font
Opacity
Sets the opacity. Defaults to AUTO. Options are AUTO, TRANSPARENT, TRANSLUCENT,
SOLID, or FLASHING.
Font Edge
Type
Sets the edge appearance — AUTO, NONE, RAISED, DEPRESSED, UNIFORM, LEFT
SHADOWED, or RIGHT SHADOWED. The default is AUTO.
Font Edge
Color
Sets the edge color — AUTO, WHITE, BLACK, RED, GREEN, BLUE, YELLOW, MAGENTA, or
CYAN. The default is AUTO.
Backgroun
d Color
Sets the background color for closed captions. Defaults to AUTO. Options are AUTO,
WHITE, BLACK, RED, GREEN, BLUE, YELLOW, MAGENTA, or CYAN.
Backgroun
d Opacity
Sets the background opacity for closed captions. Defaults to AUTO. Options are AUTO,
TRANSPARENT, TRANSLUCENT, SOLID, or FLASHING.
Settings
Sets the default settings for closed captions (AUTO) or the settings you have configured
(USER). Defaults to AUTO. Options are AUTO or USER.
Return to
Main Page
Selecting this option will return you to the User Settings Menu main screen.
Restore
Closed
Caption
Defaults
To reset all of the Additional Closed Caption settings to their default values, navigate to
this option and press the ► key.
Graphics Overlaying the Video
The IPC1100 can generate graphics that overlay the video programming or fill the entire television
screen. Common examples include on-screen menus (such as the User Setting menu), closed captions,
and IPG. The IPC1100 overlays these graphics whenever you open a menu, enable closed captions, or
scroll through a program grid.
On-screen graphics are available for all IPC1100 video outputs.
