Arris IPC1100 - Figure 9 - Example General Status Display (no Error)

Diagnostics
IPC1100 Advanced IP Client Video Set-top • Installation and Operations Manual
40
365-095-24769 x.1 10/13
Figure 26 – Example General Status display (no error)
The General Status fields are:
Field Description
Error Error codes display on the front panel and OSD when an error occurs. If multiple
errors occur, the last recorded error is displayed:
Error Code Description
E 00 No error
EP01 Not connected
EP03 DRAM error
EP04 SRAM error
EP07 ROM verification failure
EP08 RAM test failure
Error
Environment
