Diagnostics
IPC1100 Advanced IP Client Video Set-top • Installation and Operations Manual
365-095-24769 x.1 10/13
Field Description
Audio
Mode
Audio Mode indicates the audio Mode of in incoming digital service. Valid values
include:
• N/A: the audio mode is not applicable to the currently tuned stream.
• Mono: the audio mode is monophonic.
• Stereo: the audio mode is stereo.
• Surround: the audio mode is surround sound.
• 5.1: the audio mode is Dolby Digital 5.1 surround sound.
• 7.1: the audio mode is Dolby Digital 7.1.
Format
The input format includes the aspect ratio (4:3 or 16:9), the screen pixel size
(nnnnXnnnn), pixel display (‘i’ for interlaced, ‘p’ for progressive), and frames per second
(24, 25, 30, 60).
