Aruba Instant On 1930 User Manual

LED State Meaning
Fast and
slow ash /
On solid
(orange)
• Mode (Link/Act)
◦ Slow-ash orange indicates port failure, non-supported transceiver,
or transceiver failure.
• Mode (Spd)
◦ Slow-ash orange indicates port failure, non-supported transceiver,
or transceiver failure.
• Mode (PoE)
◦ On solid orange indicates PoE power is disabled on the port.
◦ Fast ash orange indicates port is denied power or is detecting an
external PD fault.
◦ Slow ash orange indicates port failure due to internal PoE specic
hardware failure.
O Port is disabled, not connected, not receiving link beat (not Linked), or not
providing PoE power.
Mode On solid
(green)
• Mode (Link/Act)
◦ Default mode. No LED indicator - Mode (Spd) and Mode (PoE) not
selected.
• Mode (Spd)
◦ On solid green - Speed Mode is selected. Port LEDs indicate port
speed.
• Mode (PoE)
◦ On solid green - PoE Mode is selected. Port LEDs show PoE
information.
On solid /
Slow ash
(orange)
• Mode (PoE) NOT Selected
◦ Slow ash orange - PoE Mode has NOT been selected. A port has an
internal PoE hardware failure.
• Mode (PoE)
◦ On solid orange - PoE Mode is selected. A port has an internal PoE
hardware failure. The specic port LED should ash simultaneously
with Global Status LED.
O • Mode (Spd) not selected.
• Mode (PoE) not selected.
Table Continued
14 Aruba Instant On 1930 Installation and Getting Started
Guide

Aruba Instant On 1930 Specifications

General

Model	Aruba Instant On 1930
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Uplink Ports	2 or 4 SFP/SFP+ ports
Management	Aruba Instant On cloud-based management
Layer 2 Features	VLAN, QoS, LACP, IGMP snooping, STP/RSTP/MSTP
Layer 3 Features	Static Routing
Power Supply	Internal (100-240V AC)
Certifications	RoHS
