Aruba Instant On 1930 User Manual

Item Description
7 Reset pushbutton (recessed)
8 LED Mode pushbutton
Figure 2: JL681A
Item Description
1 1GbE RJ45 ports with Link/Status LED per port
2 1GbE SFP port with Link/Status LED
3 Cloud Status LED
4 Global Status LED
5 UID LED
6 PoE Mode LED
7 Speed Mode LED
8 Reset pushbutton (recessed)
9 LED Mode pushbutton
Figure 3: JL682A
Chapter 2 Overview 7

Aruba Instant On 1930 Specifications

General

Model	Aruba Instant On 1930
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Uplink Ports	2 or 4 SFP/SFP+ ports
Management	Aruba Instant On cloud-based management
Layer 2 Features	VLAN, QoS, LACP, IGMP snooping, STP/RSTP/MSTP
Layer 3 Features	Static Routing
Power Supply	Internal (100-240V AC)
Certifications	RoHS
