ASCOM Ascotel 2025 - 5.4.10 Examples of LCR

ascom Ascotel 2025/2045/2065
HBT_20321104_02/B0_en Call Routing 2.171
5.4.10 Examples of LCR
Fig. 2.83: 1. Example: Network provider B is integrated in the numbering plan of network
provider A
Tab. 2.53: 1. Example: Entry in the network provider table
1. Stage:
• The system reaches network provider B via network provider A
• Network provider B seizes and the connection provider B – Ascotelis set up
2. Stage:
The system transmits the phone number in DTMF mode in accordance with the
configured conversion rule.
Network provider Access
code
Route Barring Conversion rule User ID PIN Charge code
length
Network
provider B
132 – – EN – – –
132 provider B
Subscriber dials
0-01 91 416 08 74
PBX
LCR
Network A
Network B
132 01 91 416 08 74
01 91 416 08 74
haz0134aaena0
