ascom Ascotel 2025/2045/2065
HBT_20321104_05/B0_en AIMS Configuration Tool 5.3
Note:
PBX systems running ISDN-5.1 can only be configured with AIMS 5.1 or
higher.
The AIMS and PBX versions must be installed for the same sales channel.
If the channel versions of AIMS and PBX do not match, it will not be pos-
sible to configure the PBX via AIMS.
Besides the Configuration Manager, AIMS also features a number of other Man-
agers for related tasks (see "Ascotel Information Management System AIMS",
Page 1.93).
Communication Protocol
The TCP / IP communication protocol is used for communications between PBX
and PC. The PPP protocol is used for serial connections (via V.24 for example). To
be able to set up such a connection, you need to ensure that the appropriate PPP
software is installed on the PC (see "Settings on the PC", Page 5.8).
2.2 Connection Options
Overview of Connection Options
Tab. 5.1: Connection options for configuration with AIMS
Access Connection on the PC Connection on the PBX Effective data trans-
mission rate
Local access (internal)
• via V.24 interface V.24 interface V.24 interface approx. 130 kbit/s
• via Pocket Adapter V.24 interface AD2 interface approx. 10 kbit/s
Dial-up access
• internal access ISDN TA or ISDN PC card S interface 64 kbit/s
• external access (via the
public network)
ISDN TA or ISDN PC card Network interface 64 kbit/s
LAN (Ethernet) Ethernet interface Ethernet interface (on the
basic system)
10 Mbit/s
