ascom Ascotel 2025/2045/2065
2.232 Call Logging (CL) HBT_20321104_02/B0_en
7.2 Call Logging for Outgoing Calls (OCL)
OCL is used to log the outgoing connection data of individual calls and output the
data via the system’s V.24 interface at the end of the call. OCL can be activated
and deactivated throughout the system and for each subscriber.
Output Formats
The output formats PC1...PC5 are available for output on a PC.
For the output on a printer there is a choice of a list output (protocol) or an indi-
vidual receipt output (for each call one multi-line receipt with additional text).
Only the output formats protocol and individual receipt are subject to the sur-
charge calculator allocated to the subscriber.
Fig. 2.124: Schematic sequence
(See "Output Formats", Page 2.248.)
haz0155aaenb0
PC
Journal
Printer
OFF
V.24
Metering
pulses
ON
OCL
per
SC
Output format
Protocol
Receipt
Output format
PC1...PC5
OCL OFF
