ascom Ascotel 2025/2045/2065
3.10 Expansion Stages HBT_20321104_03/B0_en
2.4.2 Subscriber Cards
Subscriber cards expand the number of user-network interfaces.
Tab. 3.6: Number of subscriber cards of one particular type per PBX
2.4.3 Special Cards
Special cards contain the hardware for applications and functions not provided by
the basic systems.
IP Card IPI-100BT
The special card IPI-100BT contains the hardware and software of the Ascotel IP
Gateway AIP6400 for the VoIP (Voice over Internet Protocol) and NoIP (Network-
ing over Internet Protocol) application, and it provides the Ethernet interface
(10/100 MBit/s and automated recognition of transmission speed) for the network
connection. The card makes it possible to network multiple PBXs in different loca-
tions via an existing voice-compatible IP network
Tab. 3.7: Resources of the IP card IPI-100BT
A separate documentation is available with details of this special card.
Card type User-network interfaces per card Max. number for
Ascotel 2025 Ascotel 2045 Ascotel 2065
SC-04AD2 4 x AD2 2 4 14
SC-08AD2 8 x AD2 1 2 14
SC-16AD2 16 x AD2 1 2 10
SC-24AD2 24 x AD2 1 1 6
SC-04AB 4 x a/b 2 4 14
SC-08AB 8 x a/b 1 2 10
ISDN-04ST 4 x S/T
1)
1)
individually switchable
128
Number
Simultaneous VoIP / NoIP connections 12
LAN subscribers 50
