3.3 Special Interfaces
The system supports a range of special interfaces.
3.3.1 Ethernet Interface
The system provides two types of Ethernet interfaces:
• Ethernet interface on the basic system
1)
for data exchange with AIMS and for
connecting a CTI server
• Ethernet interface on the IPI-100BT expansion card for connecting the Ascotel
IP Gateway to an IP network
3.3.2 V.24 Interface
The V.24 interface is a serial interface. Data transfer is asymmetrical, bipolar with
a minimum of +/- 4 V over a minimum of 3 wires (SGND, TXD, RXD). Control sig-
nals are transmitted by codes (XON, XOFF) or with additional lines for hardware
flow control.
The system provides several V.24 interfaces:
• Two V.24 interfaces directly on the mainboard
• V.24 interfaces on user-network interfaces via the Pocket Adapter
1)
The IP address can be set via AIMS and can be viewed using the System Assistant.
