ascom Ascotel 2025/2045/2065
HBT_20321104_01/B0_en Networking the Systems 1.31
4.2.2 Leased-Line Networking (Leased-Line Network)
With this type of networking, the PINXs are connected with specific or leased ded-
icated lines. The characteristics of this type of networking are:
• fixed line resources
•fixed costs
[1] Connection to the public network
[2] Physical connection between two PINXs
Fig. 1.18: Example of a leased-line network, represented in two different ways
Public network
[2]
[2]
[1]
[1]
PISN
PISN
haz0652aaena0
PINX 1
PINX 3
PINX 2
PINX 1 PINX 2
PINX 3
