AC24/30/36 Operations Manual....
35
6.4 REMOTE COMMUNICATIONS, cont.
Command Description Return Value Range
:MEASure:SP1:CURRent1 Shore Power 1 RMS Current Real number, 0 to 1000
:MEASure:SP1:CURRent2 Shore Power 2 RMS Current Real number, 0 to 1000
:MEASure:SP1:KVA1 Shore Power #1 kVA Real number, 0 to 1000
:MEASure:SP1:KVA2 Shore Power #2 kVA Real number, 0 to 1000
:MEASure:SP1:POWer1 Shore Power #1 kW Real number, 0 to 1000
:MEASure:SP1:POWer2 Shore Power #2 kW Real number, 0 to 1000
:MEASure:SP1:PF1 Shore Power Phase 1 Power Factor Real number, 0 to 1.00
:MEASure:SP1:PF2 Shore Power Phase 2 Power Factor Real number, 0 to 1.00
:MEASure:SP1:ALL VSP1,VSP2,N/A,CURR1, See above, expressed in
CURR2,N/A,FREQ 3.2 precision
:MEASure:CONVerter:FREQuency Converter Output Frequency Real number, 0 to 100
:MEASure:CONVerter:VOLTage1 Converter Phase L1 Output Voltage Real number, 0 to 1000
:MEASure:CONVerter:VOLTage2 Converter Phase L2 Output Voltage Real number, 0 to 1000
:MEASure:CONVerter:VLL1 Converter Phase L1-L2 Output Voltage Real number, 0 to 1000
:MEASure:CONVerter:CURRent1 Converter L1 RMS Current Real number, 0 to 1000
:MEASure:CONVerter:CURRent2 Converter L2 RMS Current Real number, 0 to 1000
:MEASure:CONVerter:KVA1 Converter Phase L1 kVA Real number, 0 to 1000
:MEASure:CONVerter:KVA2 Converter Phase L2 kVA Real number, 0 to 1000
:MEASure:CONVerter:POWer1 Converter Phase L1 kW Real number, 0 to 1000
:MEASure:CONVerter:POWer2 Converter Phase L2 kW Real number, 0 to 1000
:MEASure:CONVerter:PF1 Converter Phase L1 Power Factor Real number, 0 to 1.00
:MEASure:CONVerter:PF2 Converter Phase L2 Power Factor Real number, 0 to 1.00
:MEASure:CONVerter:ALL VOLT1, VOLT2, N/A, CURR1, See above, expressed in
CURR2, N/A, FREQ 3.2 precision
:MEASure:GENerator1:FREQuency Generator #1 Output Frequency Real number, 0 to 100
:MEASure:GENerator1:VOLTage1 Generator #1 Phase L1 Output Voltage Real number, 0 to 1000
:MEASure:GENerator1:VOLTage2 Generator #1 Phase L2 Output Voltage Real number, 0 to 1000
:MEASure:GENerator2:FREQuency Generator #2 Output Frequency Real number, 0 to 100
:MEASure:GENerator2:VOLTage1 Generator #2 Phase L1 Output Voltage Real number, 0 to 1000
:MEASure:GENerator2:VOLTage2 Generator #2 Phase L2 Output Voltage Real number, 0 to 1000
:MEASure:GENerator:ALL (GEN1) VOLT1, VOLT2, N/A, See above, reduced to
FREQ, (GEN2) VOLT1, VOLT2, 3.2 resolution
N/A, FREQ
