ASL INTERCOM VIPEDIA-12 User Manual

VIPEDIA-12 Products – Installation Guide
U-0641-0344.docx – Issue: 8 complete, approved
Page 22 of 52
⑬
AUDIO OUTPUTS 1-4, 5-8 and 9-12 (A&B): Audio Outputs 1 to 12 (A&B)
1
2
3
4
5
6
7
8
A
AUDIO OUTPUTS
1-4
1
2
3
4
5
6
7
8
1-4
AUDIO OUTPUTS
B
AUDIO OUTPUTS 1-4 (A&B): Standard RJ45 socket
Pin CAT5 Cable (T568B) Signal Description
1 white/orange AUDIO OUT 1+ Balanced audio output 1 (+ve)
2 orange AUDIO OUT 1- Balanced audio output 1 (-ve)
3 white/green AUDIO OUT 2+ Balanced audio output 2 (+ve)
4 blue AUDIO OUT 3+ Balanced audio output 3 (+ve)
5 white/blue AUDIO OUT 3- Balanced audio output 3 (-ve)
6 green AUDIO OUT 2- Balanced audio output 2 (-ve)
7 white/brown AUDIO OUT 4+ Balanced audio output 4 (+ve)
8 brown AUDIO OUT 4- Balanced audio output 4 (-ve)
1
2
3
4
5
6
7
8
A
AUDIO OUTPUTS
5-8
1
2
3
4
5
6
7
8
5-8
AUDIO OUTPUTS
B
AUDIO OUTPUTS 5-8 (A&B): Standard RJ45 socket
Pin CAT5 Cable (T568B) Signal Description
1 white/orange AUDIO OUT 5+ Balanced audio output 5 (+ve)
2 orange AUDIO OUT 5- Balanced audio output 5 (-ve)
3 white/green AUDIO OUT 6+ Balanced audio output 6 (+ve)
4 blue AUDIO OUT 7+ Balanced audio output 7 (+ve)
5 white/blue AUDIO OUT 7- Balanced audio output 7 (-ve)
6 green AUDIO OUT 6- Balanced audio output 6 (-ve)
7 white/brown AUDIO OUT 8+ Balanced audio output 8 (+ve)
8 brown AUDIO OUT 8- Balanced audio output 8 (-ve)
1
2
3
4
5
6
7
8
A
AUDIO OUTPUTS
9-12
1
2
3
4
5
6
7
8
9-12
AUDIO OUTPUTS
B
AUDIO OUTPUTS 9-12 (A&B): Standard RJ45 socket
Pin CAT5 Cable (T568B) Signal Description
1 white/orange AUDIO OUT 9+ Balanced audio output 9 (+ve)
2 orange AUDIO OUT 9- Balanced audio output 9 (-ve)
3 white/green AUDIO OUT 10+ Balanced audio output 10 (+ve)
4 blue AUDIO OUT 11+ Balanced audio output 11 (+ve)
5 white/blue AUDIO OUT 11- Balanced audio output 11 (-ve)
6 green AUDIO OUT 10- Balanced audio output 10 (-ve)
7 white/brown AUDIO OUT 12+ Balanced audio output 12 (+ve)
8 brown AUDIO OUT 12- Balanced audio output 12 (-ve)
