ASL INTERCOM VIPEDIA-12 User Manual

VIPEDIA-12 Products – Installation Guide
U-0641-0344.docx – Issue: 8 complete, approved
Page 40 of 52
7.3.2.7 BOA02 - RS232 Serial Port Connections
Field Connection
Connection to VIPEDIA-12
(via CAT5 patch lead)
To/From
external
device
Screw Terminal
BOA02’s
RJ45
(see page 36)
PORT 1 to 4
VIPEDIA-12’s
RJ45
(see page 16)
⑧
Description Signal Pin Pin T568B Pin
Not connected – 1 1 WH/OR 1
RS232 Received Data RX 2 2 OR 2
RS232 Transmitted Data TX 3 3 WH/GR 3
Not connected – 4 6 GR 6
Data Terminal Ready DTR 5 4 BL 4
Common Ground GND 6 5 WH/BL 5
Request To Send RTS 7 7 WH/BR 7
Clear To Send CTS 8 8 BR 8
7.3.2.8 BOA02 - AMP CTRL Port Connections
Field Connection
Connection to VIPEDIA-12
(via CAT5 patch lead)
To/From
external
device
Screw Terminal
BOA02’s
RJ45
(see page 36)
PORT 1 to 4
VIPEDIA-12’s
RJ45
(see page 16)
⑨
Description Signal Pin Pin T568B Pin
Controller Area Network (High) CAN_H 1 1 WH/OR 1
Controller Area Network (Low) CAN_L 2 2 OR 2
0 V Reference GND 3 3 WH/GR 3
0 V Reference GND 4 6 GR 6
Audio Monitor Bus (–10 dBu nominal)
(+ve)
AUDIO MON+ 5 4 BL 4
As above but –ve AUDIO MON- 6 5 WH/BL 5
Amplifier control data / EIA RS485 9600
baud (Data+)
DXP 7 7 WH/BR 7
As above but Data- DXN 8 8 BR 8
