VIPEDIA-12 Products – Installation Guide
U-0641-0344.docx – Issue: 8 complete, approved
Page 39 of 52
7.3.2.5 BOA02 - Contact Outputs (1 to 12) Connections
Field Connection
Connection to VIPEDIA-12
(via CAT5 patch lead)
To/From
external
device
Screw Terminal
BOA02’s
RJ45
(see page 36)
PORT 1 to 4
VIPEDIA-12’s
RJ45
(see page 16)
②
Description Signal Pin Pin T568B Pin
Open-drain output 1 [7] Contact 1 [7] 1 1 WH/OR 1
Open-drain output 2 [8] Contact 2 [8] 2 2 OR 2
Open-drain output 3 [9] Contact 3 [9] 3 3 WH/GR 3
Open-drain output 4 [10] Contact 4 [10] 4 6 GR 6
Open-drain output 5 [11] Contact 5 [11] 5 4 BL 4
Open-drain output 6 [12] Contact 6 [12] 6 5 WH/BL 5
+ve supply (as 18V-40 V power supply
input) for open-drain outputs
+Supply 7 7 WH/BR 7
+ve supply (as 18V-40 V power supply
input) for open-drain outputs
+Supply 8 8 BR 8
Open-drain output:
• Numbers without brackets refer to CONTACTS OUT 1-6 connector
• Numbers within brackets refer to CONTACTS OUT 7-12 connector
7.3.2.6 BOA02 - Fault/Voice Alarm/Control Relay and BMB01 Connections
Field Connection
Connection to VIPEDIA-12
(via CAT5 patch lead)
To/From
external
device
Screw Terminal
BOA02’s
RJ45
(see page 36)
PORT 1 to 4
VIPEDIA-12’s
RJ45
(see page 16)
⑪
Description Signal Pin Pin T568B Pin
Fault relay N/C contact Relay 1 N/C 1 1 WH/OR 1
Fault relay COM contact Relay 1 COM 2 2 OR 2
Fault relay N/O contact Relay 1 N/O 3 3 WH/GR 3
Voice Alarm/Control relay N/C contact Relay 2 N/C 4 6 GR 6
Voice Alarm/Control relay COM contact Relay 2 COM 5 4 BL 4
Voice Alarm/Control relay N/O contact Relay 2 N/O 6 5 WH/BL 5
BMB control data / EIA RS485 9600
baud (Data+)
BMB DXP 7 7 WH/BR 7
As above but Data- BMB DXN 8 8 BR 8
