ASL INTERCOM VIPEDIA-12 User Manual

VIPEDIA-12 Products – Installation Guide
U-0641-0344.docx – Issue: 8 complete, approved
Page 26 of 52
7.3.1.1 BOA01 - Audio Input and Serial Interface (1 to 12) Connections
Field Connection
Connection to VIPEDIA-12
(via CAT5 patch lead)
Screw Terminal
①
From
external
power supply
Description Signal Pin
Not applicable
(Connected to screw terminal
③
via the PCB.)
+V supply input (18 – 40 V) / 500 mA 24 V 1
+V supply input (18 – 40 V) / 500 mA 24 V 2
0 V supply 0 V 3
To/From
external
device (e.g.
ASL
microphone)
Screw Terminal
②
BOA01’s
RJ45
(see page 25)
④
VIPEDIA-12’s
RJ45
(see page 16)
⑫
INPUTS 1 to 12
Description Signal Pin Pin T568B Pin
Balanced audio input+ AUDIO IN+ 1 1 WH/OR 1
Balanced audio input- AUDIO IN- 2 2 OR 2
RS485 data+ DXP 3 3 WH/GR 3
RS485 data- DXN 4 6 GR 6
DC supply output (18 – 40 V) +SUPPLY 5 4 BL 4
DC supply output (18 – 40 V) +SUPPLY 6 5 WH/BL 5
DC supply output (0 V) 0V 7 7 WH/BR 7
DC supply output (0 V) 0V 8 8 BR 8
Screw Terminal
③
Not applicable
Description Signal Pin
Cable screen SCREEN 1
DC supply output (18 – 40 V) SUPPLY+ 2
Cable screen SCREEN 3
DC supply output (0 V) 0V 4
Cable screen SCREEN 5
DC supply output (18 – 40 V) SUPPLY+ 6
Cable screen SCREEN 7
DC supply output (0 V) 0V 8

An external DC power supply (18 – 40 V) must be connected to screw terminal ① if the external device is to be
powered from the screw terminal block
③.
