ASL INTERCOM VIPEDIA-12 User Manual

VIPEDIA-12 Products – Installation Guide
U-0641-0344.docx – Issue: 8 complete, approved
Page 34 of 52
7.3.1.8 BOA01 - AMP CTRL Port Connections
Field Connection
Connection to VIPEDIA-12
(via CAT5 patch lead)
Screw Terminal
①
From
external
power supply
Description Signal Pin
Not applicable
(Connected to screw terminal
③
via the PCB.)
+V supply input (18 – 40 V) / 500 mA 24 V 1
+V supply input (18 – 40 V) / 500 mA 24 V 2
0 V supply 0 V 3
To/From
external
device
Screw Terminal
②
BOA01’s
RJ45
(see page 25)
④
VIPEDIA-12’s
RJ45
(see page 16)
⑨
Description Signal Pin Pin T568B Pin
Controller Area Network (High) CAN_H 1 1 WH/OR 1
Controller Area Network (Low) CAN_L 2 2 OR 2
0 V Reference GND 3 3 WH/GR 3
0 V Reference GND 4 6 GR 6
Audio Monitor Bus (–10 dBu nominal)
(+ve)
AUDIO MON+ 5 4 BL 4
As above but –ve AUDIO MON- 6 5 WH/BL 5
Amplifier control data / EIA RS485 9600
baud (Data+)
DXP 7 7 WH/BR 7
As above but Data- DXN 8 8 BR 8
Screw Terminal
③
Not applicable
Description Signal Pin
Cable screen SCREEN 1
DC supply output (18 – 40 V) SUPPLY+ 2
Cable screen SCREEN 3
DC supply output (0 V) 0V 4
Cable screen SCREEN 5
DC supply output (18 – 40 V) SUPPLY+ 6
Cable screen SCREEN 7
DC supply output (0 V) 0V 8

An external DC power supply (18 – 40 V) must be connected to screw terminal ① if the external device is to be
powered from the screw terminal block
③.
