VIPEDIA-12 Products – Installation Guide
U-0641-0344.docx – Issue: 8 complete, approved
Page 33 of 52
7.3.1.7 BOA01 - RS232 Serial Port Connections
Field Connection
Connection to VIPEDIA-12
(via CAT5 patch lead)
Screw Terminal
①
From
external
power supply
Description Signal Pin
Not applicable
(Connected to screw terminal
③
via the PCB.)
+V supply input (18 – 40 V) / 500 mA 24 V 1
+V supply input (18 – 40 V) / 500 mA 24 V 2
0 V supply 0 V 3
To/From
external
device
Screw Terminal
②
BOA01’s
RJ45
(see page 25)
④
VIPEDIA-12’s
RJ45
(see page 16)
⑧
Description Signal Pin Pin T568B Pin
Not connected – 1 1 WH/OR 1
RS232 Received Data RX 2 2 OR 2
RS232 Transmitted Data TX 3 3 WH/GR 3
Not connected – 4 6 GR 6
Data Terminal Ready DTR 5 4 BL 4
Common Ground GND 6 5 WH/BL 5
Request To Send RTS 7 7 WH/BR 7
Clear To Send CTS 8 8 BR 8
Screw Terminal
③
Not applicable
Description Signal Pin
Cable screen SCREEN 1
DC supply output (18 – 40 V) SUPPLY+ 2
Cable screen SCREEN 3
DC supply output (0 V) 0V 4
Cable screen SCREEN 5
DC supply output (18 – 40 V) SUPPLY+ 6
Cable screen SCREEN 7
DC supply output (0 V) 0V 8
An external DC power supply (18 – 40 V) must be connected to screw terminal ① if the external device is to be
powered from the screw terminal block
③.
