ASL INTERCOM VIPEDIA-12 User Manual

VIPEDIA-12 Products – Installation Guide
U-0641-0344.docx – Issue: 8 complete, approved
Page 46 of 52
8 Technical Specification
General
Power Supply ............................................................................................................. dual 18 V to 40 V DC (2 A)
Current Consumption at 24 V DC
VIPEDIA-12 (excluding optional modules, microphones and other peripherals)
Minimum (LCD display backlight off, LEDs off and sounder off) ................................................ 445 mA
Maximum (LCD display backlight on, LEDs on and sounder on) .............................................. 490 mA
1
Network Card ..................................................................................................................... Additional 145 mA
Dante Brooklyn II Module .................................................................................................... Additional 60 mA
SFP Module ...................................................................................................... Additional 30 mA per module
Built-in DVA Storage
2
.................................................................................... DVA storage (up to 63 messages)
48 kHz 16 bit mono WAV files (10 minutes audio time)
24 kHz 16 bit mono WAV files (20 minutes audio time)
12 kHz 16 bit mono WAV files (40 minutes audio time)
Real Time Clock (RTC) ................................................................................. Built-in (externally synchronisable)
Front Panel Display and Indicators ....................................... EN 54-16, ISO 7240-16 and BS 5839-8 compliant
IP Connectivity ................................................................................. 2 x 100BASE-T Ethernet (RJ45) (standard)
2 x 100BASE-T Ethernet (RJ45) + 2 x 1 GigE SFP
3
Modules (RJ45 or MM/SM fibre) (on the Network Card)
Temperature .................................................................. -20°C to +55°C (storage) / -10°C to +55°C (operation)
Humidity Range ....................................................................................................... 0% to 93% non-condensing
IP Rating ....................................................................................................................................................... IP20
Dimensions (H x W x D) ........ 41.8 mm (1U) x 436 mm x 260 mm (excluding handles) / 19-inch rack mounting
Weight ....................................................................................................................................................... 3.75 kg
Optional Modules (see Part Codes)
Network Card (factory fit) .................................................... Audio over IP (PMC) and additional IP connectivity
1 x USB OTG for diagnostic purposes (USB Micro-AB)
Optional ASL VIPA software suite applications
4
such as DVA and TTS (Text To Speech)
Dante Brooklyn II Module (factory fit) ............................. Dante™ capability via Audinate® Brooklyn II module
5
Terminal Server (factory fit) ........................................................................ TCP/IP to serial protocol conversion
SFP Modules (1 GigE)
6
.................................................................... MM (multimode fibre) module / LC duplex
SM (single mode fibre) module / LC duplex
RJ45 (copper) module
Part Codes
7
VIPEDIA-12 .......................................................................................... VIPEDIA-12 without Network Card fitted
VIPEDIA-12-NET ....................................................................................... VIPEDIA-12 with Network Card fitted
VIPEDIA-12-PRO ..................................... VIPEDIA-12 with Network Card and Dante Brooklyn II module fitted
VIPEDIA-12-TS1 .................................................................................... VIPEDIA-12 with Terminal Server fitted
1
LCD backlight current consumption: approx. 10 mA.
2
24 kHz and 12 kHz DVAs require software version V3.2.0.2 (or later).
3
SFP modules: refer to ASL for availability and compatibility.
4
VIPA applications: refer to ASL for availability and compatibility.
5
Audinate® is a registered trademark of Audinate Pty Ltd.
Dante™ is a trademark of Audinate Pty Ltd.
6
SFP modules: refer to ASL for availability and compatibility.
7
Refer to ASL for latest product list and part codes.
