Associated Research OMNIA II 8204 User Manual

15
DIELECTRIC WITHSTAND TEST MODE (CONT.)
Current Display
AC Total
AC Real
DC
Auto Range*
Range 1: 0.000 mA – 3.500 mA RMS
(0.000 mA – 5.500 mA Peak)
Resolution: 0.001 mA
Range 2 3.00 mA – 50.00 mA RMS
(5.00 mA – 70.07 mA Peak)
Resolution: 0.01 mA
Accuracy:  (2% of reading + 2 counts) All Ranges
Range 1: 0.000 mA – 9.999 mA
Resolution: 0.001 mA
Range 2: 10.00 mA – 50.00 mA
Resolution: 0.01 mA
Accuracy:  (3% of reading + 50A) All Ranges
PF > 0.1
V > 250VAC
Range 1: 0.0 A – 350.0 A DC
(0.0 A – 550.0 A Peak)
Resolution: 0.1 A
Range 2 : 0.300 mA –3.500 mA DC
(0.400 mA –5.500 mA Peak)
Resolution: 0.001 mA
Range 3 3.00 mA – 20.00 mA DC
(4.00 mA – 25.00 mA Peak)
Resolution: 0.01 mA
Accuracy:  (2% of reading + 2 counts) All Ranges
DC Output Ripple
 4% Ripple RMS at 5 KV DC @ 20mA, Resistive Load
Discharge Time
 50 ms no load, < 100 ms for capacitive load
Maximum Capacitive
Load
DC Mode
1uF < 1KV
0.75uF < 2KV
0.5uF < 3KV
0.08uF < 4KV
0.04uF < 6KV
AC Output
Waveform
Sine Wave, Crest Factor = 1.3 – 1.5
Output Frequency
Range: 60 or 50 Hz, User Selection
Accuracy:  0.1 %
Output Regulation
 (1 % of output + 5 V)
from no load to full load and over input voltage range.
Dwell Timer
Range: AC 0.4 –999.9 sec (0 = Continuous)
Range: DC 0.3 –999.9 sec (0 = Continuous)
Resolution: 0.1 sec
Accuracy:  (0.1% + 0.05 sec)
Ramp Timer
Range: Ramp-Up: AC 0.1 – 999.9 sec
DC 0.4 – 999.9 sec
Ramp-Down: AC 0.0 – 999.9 sec
DC 0.0 , 1.0 – 999.9 sec
Resolution: 0.1 sec
