Associated Research OMNIA II 8204 User Manual

138
8. OPTIONS
Introduction
This section contains a list and descriptions of available factory installed options
at the time of this printing. The list of options contains an option code number
that can be referenced on the data plate on the rear panel of the unit.
Option Label
On the rear panel of the instrument, you will find a label that contains the option
code.
For example, your options code would appear as follows:
Fitted with option 01..........................................
OPT: 01
Fitted with option 01 and 05..............................
OPT: 0105
Option List
CODE
DESCRIPTION
01
Internal Scanner
03
Dual Remote Test Switches
04
OMNIA to APT 3 Memory (Discontinued)
05
OMNIA to APT 7 Memory
06
Cold Resistance
07
Data Storage Card (Discontinued)
08
Printer Port
09
Ethernet Card
10
GPIB Card
11
DUT Output Relay Controls (8206 Only)
14
400/800 Hz Hipot Output (8206 Only)
15
3mA AC/DC Output (Discontinued)
16
Prompt Interlock (Discontinued)
17
GB Volt (Discontinued)
51
PLC Voltage Control (Discontinued)
52
15 Remote Memories Select (Discontinued)
54
Reactive Current (Discontinued)
55
31 Remote Memories Select (Discontinued)
56
Power Tracking (8206 Only)
57
Hardware Interlock
58
Disable RUN/LLT GFI
01 8 Channel Scanner
The Scanner option provides 8 high Voltage/Continuity channels and 8 Ground
Bond/Continuity channels on the rear panel. The High Voltage/Continuity
channels can be set to a High or Low level, giving the capability to test from one
