Associated Research OMNIA II 8204 User Manual

224
11. REPLACEMENT PARTS LIST
Rev: H 11/30/2015 ECO 5802
PART
NUMBER
QTY.
REF.
DESIGNATOR
DESCRIPTION
Supplied Accessories
38788
2
-
3U Rack Mount Bracket
38787
2
-
3U Rack Mount Handle
38549
4
-
Screw for Rack Mount Handle
38503
1
-
Fuse 10A 250V Slow-Blow 20mm
04040A-08
1
-
High Voltage Cable
39066
1
-
USB Cable AB-Type 1.8m
33189
1
-
Cable Input Cordset USA
38075
1
-
Interlock Connector
38482
1
-
Adapter Box
0404A-08
1(3)
-
High Voltage Cable (3) for
8206,07,56,57
CBLHC40-
10TL
1
-
Case wire for 8206,07,56,57
38489
1
-
Cable Assembly High Current
Output
38490
1
-
Cable Assembly High Current
Return
Panel Components
38364
1
-
Fuse Holder 20mm
37478
2
-
High Voltage Connector
37555
1
-
Power Switch 2P 10A/250V
37571
1
-
Earth Connector
37806
1
TEST
Test Switch Green Lighted
37807
1
RESET
Reset Switch Red Lighted
39391
1
TEST
Replacement Bulb
39392
1
RESET
Replacement Bulb
38101
1
-
Feet Kit w/o Rubber Inserts
38102
4
-
Rubber Insert for Feet
39678
1
-
LCD Color Display
39679
4
-
EVA Rubber Blocks for LCD Display
38487
2
-
Socket 80 Amp Red
38488
2
-
Socket 80 Amp Black
PCB Assemblies
39306
1
AMP7800
Amplifier Board
39307
1
ANG7800
Analog Board
39308
1
CON7800
Main Control Board
39309
1
FB7800
Feedback Board (820X)
39310
1
FIL7800
Filter Board
39311
1
HV7800
High Voltage Control Board (820X)
