Associated Research OMNIA II 8204 User Manual

225
PART
NUMBER
QTY.
REF.
DESIGNATOR
DESCRIPTION
39312
1
KEY7800
Key Board
39313
1
PWM7800
PWM Board
39352
1
FB7800
Feedback Board (825X)
39359
1
HV7800
High Voltage Control Board (825X)
39366
1
LCT7800
LCT Board
39373
1
MD7800
Measuring Device Board
39367
1
LAM7800
LCT AC/DC Filter Board
39063
1
USB/RS232
USB/RS232 Interface Board
38305
1
CGP-03
GPIB Interface Board
38543
1
CSU7500
Scanner Control Board
38819
1
38818
Ethernet Card
Internal Components
37374
1
IC 36
IC 27512 EEPROM
39337
1
T3
Ground Bond Transformer
38336
1
T2
High Voltage Output Transformer
39347
1
IC 10 Main Board
IC 39VF040 Flash Memory
39360
1
-
500VA High Voltage Output
Transformer
39385
1
T4
Isolation Transformer
39384
1
7800T1
LCT Power Supply Transformer
38846
1
IC 8 Analog
Board
IC W78E516B
38298
1
IC 9 Analog
Board
IC ATF16V8B 20PIN PLCC
