3. SPECIFICATIONS AND CONTROLS
3.1. OMNIA II Functional Specifications
INPUT
Voltage
115 / 230V auto-range,  15  variation
Frequency
50/60 Hz  5%
Fuse
115 VAC, 230VAC – 10A Slow-Blo 250VAC
DIELECTRIC WITHSTAND TEST MODE
Output Rating
5KV @ 50mA AC
5KV @ 100mA AC (Models 825x)
6KV @ 20 mA DC
Voltage Setting
Range: 0–5000V AC
0–6000V DC
Resolution: 1 V
Accuracy:  (2% of setting + 5 volts)
Voltage Display
Range: 0.00 – 6.00KV Full Scale
Resolution: 0.01 KV
Accuracy:  (2% of reading + 1 count)
Ramp-HI DC
>20 mA peak maximum, ON/OFF Selectable
Charge-LO DC
Range: 0.0 – 350.0 A DC or Auto set
HI and LO-Limit
AC Total
AC Real
DC
Range: 0.000 – 9.999mA
Resolution: 0.001mA
Range: 10.00 – 50.00mA (100.00mA, Models 825x)
Resolution: 0.01mA
Accuracy:  (2% of setting + 2 counts)
Range: 0.000 – 9.999mA
Resolution: 0.001mA
Range: 10.00 – 50.00mA (99.99mA, Models 825x)
Resolution: 0.01mA
Accuracy:  (3% of setting + 50 A)
Range: 0.0 – 999.9A
Resolution: 0.1A
Range: 1000 – 20000A
Resolution: 1A
Accuracy:  (2% of setting + 2 counts)
Arc Detection
Range: 1 – 9
Ground Continuity
Current : DC 0.1 A  0.01A, fixed
Max. ground resistance : 1   0.1, fixed
Ground Fault
Interrupt
GFI Trip Current: 0.4mA - 5.0mA (AC or DC)
HV Shut Down Speed:  1mS
