Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
84
● Specifications
SDI output is only at the timing corresponding to each supported SDI standard (SMPTE) below.
［Component image format SMPTE 259M］
Rate
Standard
Details
270 Mb/s
SMPTE 259M
SD-SDI
Interlace
720 x 480,
720 x 525
525/59.94i
625/50i
YCbCr 4:2:2 10 bit
［1080 Line source image format SMPTE 274M］
Rate
Standard
Details
1.485 Gb/s
SMPTE 274M
HD-SDI
Interlace
Progressive
Segmented Frame
1920 x 1080
60i, 59.94i,
30p, 29.97p,
50i, 25p,
24p, 23.98p,
30PsF, 29.97PsF,
25PsF, 24PsF,
23.98PsF
YCbCr 4:2:2 10 bit
［720 Line source image format SMPTE 296M］
Rate
Standard
Details
1.485 Gb/s
SMPTE296M
HD-SDI
Progressive
1280 x 720
60p, 59.94p,
50p, 25p,
30p, 29.97p,
24p, 23.98p
YCbCr 4:2:2 10 bit
［1080 Line source image format SMPTE 372］
Rate
Standard
Details
1.485 Gb/s
x2
SMPTE 372M
DUAL LINK
Progressive
1920 x 1080
60p, 59.94p, 50p
YCbCr 4:2:2 10 bit
SMPTE 372M
DUAL LINK
Interlace
Progressive
Segmented Frame
1920 x 1080
60i, 59.94i,
30p, 29.97p,
25p, 24p, 23.98p,
30PsF, 29.97PsF,
25PsF, 24PsF,
23.98PsF
YCbCr 4:2:2 12 bit
YCbCr 4:4:4 10 bit
YCbCr 4:4:4 12 bit
RGB 4:4:4 10 bit
RGB 4:4:4 12 bit
SMPTE 372M
DUAL LINK
Progressive
Segmented Frame
2048 x 1080
60i, 59.94i,
30p, 29.97p,
25p, 24p, 23.98p,
30PsF, 29.97PsF,
25PsF, 24PsF,
23.98PsF
YCbCr 4:2:2 12 bit
YCbCr 4:4:4 10 bit
YCbCr 4:4:4 12 bit
RGB 4:4:4 10 bit
RGB 4:4:4 12 bit
