Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
85
［1080/720 Line source image format SMPTE 425-1］
Rate
Standard
Details
2.97 Gb/s
SMPTE ST 425-1
3G-SDI
Progressive
1920 x 1080
60p, 59.94p, 50p
YCbCr 4:2:2 10 bit
SMPTE ST 425-1
3G-SDI
Progressive
2048 x 1080
60p, 59.94p, 50p,
48p, 47.95p
YCbCr 4:2:2 10 bit
SMPTE ST 425-1
3G-SDI
Interlace
Progressive
Segmented Frame
1920 x 1080
60i, 59.94i, 50i,
30p, 29.97p, 25p,
24p, 23.98p
30PsF, 29.97PsF,
25PsF,
24PsF, 23.98PsF
YCbCr 4:2:2 12 bit
YCbCr 4:4:4 10 bit
YCbCr 4:4:4 12 bit
RGB 4:4:4 10 bit
RGB 4:4:4 12 bit
SMPTE ST 425-1
3G-SDI
Progressive
1280 x 720
60p, 59.94p, 50p,
30p, 29.97p, 25p,
24p, 23.98p
YCbCr 4:4:4 10 bit
RGB 4:4:4 10 bit
* 4:4:4 format of 720p supports only Level.A.
［2160/1080 Line source image format SMPTE 425-3］
Rate
Standard
Details
2.97 Gb/s
x2
SMPTE ST 425-3
3G-SDI Dual Link
Progressive
1920 x 1080
60p, 59.94p, 50p
YCbCr 4:2:2 12 bit
YCbCr 4:4:4 10 bit
RGB 4:4:4 10 bit
SMPTE ST 425-3
3G-SDI Dual Link
Progressive
2048 x 1080
60p, 59.94p, 50p,
48p, 47.95p
YCbCr 4:2:2 12 bit
YCbCr 4:4:4 10 bit
RGB 4:4:4 10 bit
SMPTE ST 425-3
3G-SDI Dual Link
Progressive : 2SI
3840 x 2160
30p, 29.97p, 25p,
24p, 23.98p
YCbCr 4:2:2 10 bit
YCbCr 4:2:0 10 bit
SMPTE ST 425-3
3G-SDI Dual Link
Progressive : 2SI
4096 x 2160
30p, 29.97p, 25p,
24p, 23.98p
YCbCr 4:2:2 10 bit
* 2160 Line supports only Level.B.
