Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
86
［2160 Line source image format SMPTE 425-5］
Rate
Standard
Details
2.97 Gb/s
x4
SMPTE ST 425-1
3G-SDI Quad Link
Progressive
3840 x 2160
60p, 59.94p, 50p
YCbCr 4:2:2 10 bit
YCbCr 4:2:0 10 bit
SMPTE ST 425-1
3G-SDI Quad Link
Progressive
4096 x 2160
60p, 59.94p, 50p,
48p, 47.95p
YCbCr 4:2:2 10 bit
SMPTE ST 425-1
3G-SDI Quad Link
Progressive
3840 x 2160
30p, 29.97p, 25p,
24p, 23.98p
YCbCr 4:2:2 12 bit
YCbCr 4:4:4 10 bit
YCbCr 4:4:4 12 bit
RGB 4:4:4 10 bit
RGB 4:4:4 12 bit
SMPTE ST 425-1
3G-SDI Quad Link
Progressive
4096 x 2160
30p, 29.97p, 25p,
24p, 23.98p
YCbCr 4:2:2 12 bit
YCbCr 4:4:4 10 bit
YCbCr 4:4:4 12 bit
RGB 4:4:4 10 bit
RGB 4:4:4 12 bit
［2160Line source image format HD-SDI Quad Link］
Rate
Standard
Details
1.485 Gb/s
x4
Quad LINK
Progressive
Segmented Frame
3840 x 2160
30p, 29.97p, 25p,
24p, 23.98p
30PsF, 29.97PsF,
25PsF,
24PsF, 23.98PsF
YCbCr 4:2:2 10 bit
Quad LINK
Progressive
Segmented Frame
4096 x 2160
30p, 29.97p, 25p,
24p, 23.98p
30PsF, 29.97PsF,
25PsF,
24PsF, 23.98PsF
YCbCr 4:2:2 10 bit
