Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
87
[2160/1080 Line source image format SMPTE 2081-10] * Only supported for VM-1876-MB.
Rate
Standard
Details
5.94 Gb/s
SMPTE ST 2081-10
6G-SDI
Progressive : 2SI
1920 x 1080
60p, 59.94p, 50p
YCbCr 4:2:2 12 bit
YCbCr 4:4:4 10 bit
YCbCr 4:4:4 12 bit
RGB 4:4:4 10 bit
RGB 4:4:4 12 bit
SMPTE ST 2081-10
6G-SDI
Progressive : 2SI
2048 x 1080
60p, 59.94p, 50p,
48p, 47.95p
YCbCr 4:2:2 12 bit
YCbCr 4:4:4 10 bit
YCbCr 4:4:4 12 bit
RGB 4:4:4 10 bit
RGB 4:4:4 12 bit
SMPTE ST 2081-10
6G-SDI
Progressive : 2SI
3840 x 2160
30p, 29.97p, 25p,
24p, 23.98p
YCbCr 4:2:2 10 bit
YCbCr 4:2:0 10 bit
SMPTE ST 2081-10
6G-SDI
Progressive : 2SI
4096 x 2160
30p, 29.97p, 25p,
24p, 23.98p
YCbCr 4:2:2 10 bit
[2160 Line source image format SMPTE 2081-11] * Only supported for VM-1876-MB.
Rate
Standard
Details
5.94 Gb/s
x2
SMPTE ST 2081-10
6G-SDI Dual Link
Progressive : 2SI
3840 x 2160
60p, 59.94p, 50p
YCbCr 4:2:2 10 bit
YCbCr 4:2:0 10 bit
SMPTE ST 2081-10
6G-SDI Dual Link
Progressive : 2SI
4096 x 2160
60p, 59.94p, 50p,
48p, 47.95p
YCbCr 4:2:2 10 bit
SMPTE ST 2081-10
6G-SDI Dual Link
Progressive : 2SI
3840 x 2160
30p, 29.97p, 25p,
24p, 23.98p
YCbCr 4:2:2 12 bit
YCbCr 4:2:0 12 bit
YCbCr 4:4:4 10 bit
YCbCr 4:4:4 12 bit
RGB 4:4:4 10 bit
RGB 4:4:4 12 bit
SMPTE ST 2081-10
6G-SDI Dual Link
Progressive : 2SI
4096 x 2160
30p, 29.97p, 25p,
24p, 23.98p
YCbCr 4:2:2 12 bit
YCbCr 4:4:4 10 bit
YCbCr 4:4:4 12 bit
RGB 4:4:4 10 bit
RGB 4:4:4 12 bit
