Asus P8H77-M User Manual

1-17第一章：產品介紹
P8H77-M 主板內存合格供應商列表（QVL）
DDR3-1066MHz
（下頁繼續）
DDR3-1333MHz
供應商 型號 容量 SS/DS 芯片廠牌 芯片型號 時序 電壓
支持內存插槽
（選配）
A B C
Crucial CT12864B
A1067.8FF
1GB SS Micron 9GF22D9KPT 7 - • • •
Crucial CT25664B
A1067.16FF
2GB DS Micron 9HF22D9KPT 7 - • • •
ELPIDA EBJ10UE8E
DF0-AE-F
1GB SS ELPIDA J1108EDSE-DJ-F - 1.35V
(low voltage)
• • •
ELPIDA EBJ21UE8E
DF0-AE-F
2GB DS ELPIDA J1108EDSE-DJ-F - 1.35V
(low voltage)
• • •
KINGSTON KVR1066
D3N7/1G
1GB SS ELPIDA J1108BFSE-DJ-F 7 1.5V • • •
KINGSTON KVR1066
D3N7/2G
2GB DS ELPIDA J1108BDSE-DJ-F 7 1.5V • • •
KINGSTON KVR1066
D3N7/4G
4GB DS Hynix H5TQ2G83AFR 7 1.5V • • •
Micron MT8JTF12864
AZ-1G1F1
1GB SS Micron 9GF22D9KPT 7 - • • •
Micron MT16JTF25664
AZ-1G1F1
2GB DS Micron 9HF22D9KPT 7 - • • •
Kingtiger 2GB DIMM
PC3-8500
2GB DS Hynix H5TQ1G83AFP
G7C
- - • • •
供應商 型號 容量 SS/DS 芯片廠牌 芯片型號 時序 電壓
支持內存插槽
（選配）
A B C
A-DATA AD3133
3001GOU
1GB SS A-Data AD30908C8
D-151C
E0906
- - • • •
A-DATA AD3U13
33C2G9
2GB SS A-DATA 3CCD-1509
HNA1126L
- - • • •
A-DATA AD63I1B
0823EV
2GB SS A-Data 3CCA-1509A - - • • •
A-DATA AM2U13
9C2P1
2GB SS ADATA 3CCD-1509
A EL1127T
- - • • •
A-DATA AX3U1333
C2G9-BP
2GB SS - - - - • • •
A-DATA AXDU1333
GC2G9-
2G(XMP)
4GB
(2 x 2GB)
SS - - 9-9-9-24 1.25V-1.35V
(low voltage)
• • •
A-DATA AD63I1C
1624EV
4GB DS A-Data 3CCA-1509A - - • • •
A-DATA AM2U13
9C4P2
4GB DS ADATA 3CCD-1509A
EL1127T
- - • • •
A-DATA SU3U1333
W8G9-B
8GB DS ELPIDA J4208BASE-
DJ-F
- - • • •

Asus P8H77-M Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200 MHz
Supported memory module capacities	16GB, 1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA III connectors	2
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel H77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Cables included	SATA
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	2-Way CrossFireX, LucidLogix Virtu, Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x4, 1x16
LAN controller	Realtek RTL8111F
Wi-Fi standards	Not supported
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Width	245 mm
