華碩 P8H77-M 主板用戶手冊1-18
DDR3-1333MHz
供應商 型號 容量 SS/DS 芯片廠牌 芯片型號 時序 電壓
支持內存插槽
（選配）
A B C
Apacer 78.A1GC6.9L1 2GB DS Apacer AM5D5808
DEWSBG
- - • • •
Apacer 78.A1GC6.9L1 2GB DS Apacer AM5D5808
FEQSBG
9 - • • •
Apacer AU02GFA33
C9NBGC
2GB DS Apacer AM5D5808
APQSBG
- - • • •
Apacer 78.B1GD
E.9L10C
4GB DS Apacer AM5D5908
CEHSBG
- - • • •
CORSAIR CM3X10
24-1333C9
1GB SS - - 9-9-9-24 1.60V • • •
CORSAIR TR3X3G
1333C9 G
3GB
(3 x 1GB)
SS - - 9-9-9-24 1.50V • • •
CORSAIR CMD24GX3M6
A1333C9(XMP)
24GB
(6x4GB)
DS - - 9-9-9-24 1.60V • • •
CORSAIR TW3X4G13
33C9D G
4GB
(2 x 2GB)
DS - - 9-9-9-24 1.50V • • •
CORSAIR CM3X4GA13
33C9N2
4GB DS CORSAIR 256MBDCJ
GELC0401136
9-9-9-24 - • • •
CORSAIR CMX4GX3M1
A1333C9
4GB DS - - 9-9-9-24 1.50V • • •
CORSAIR CMD8GX3M4
A1333C7
8GB
(4 x 2GB)
DS - - 7-7-7-20 1.60V • • •
Crucial CT12864BA
1339.8FF
1GB SS Micron 9FF22D9KPT 9 - • • •
Crucial CT25664BA
1339.16FF
2GB DS Micron 9KF27D9KPT 9 - • • •
Crucial BL25664BN
1337.16FF (XMP)
6GB
(3 x 2GB)
DS - - 7-7-7-24 1.65V • • •
ELPIDA EBJ10UE8E
DF0-DJ-F
1GB SS ELPIDA J1108ED
SE-DJ-F
- 1.35V
(low voltage)
• • •
G.SKILL F3-10600CL
8D-2GBHK(XMP)
1GB SS G.SKILL - - - • • •
G.SKILL F3-10600CL
9D-2GBNQ
2GB
(2 x 1GB)
SS - - 9-9-9-24 1.5V • • •
G.SKILL F3-10666CL7
T-3GBPK(XMP)
3GB
(3 x 1GB)
SS - - 7-7-7-18 1.5~1.6V • • •
G.SKILL F3-10666CL8
D-4GBECO(XMP)
4GB
(2 x 2GB)
DS - - 8-8-8-
8-24
XMP 1.35V • • •
G.SKILL F3-10666CL7
D-8GBRH(XMP)
8GB
(2 x 4GB)
DS - - 7-7-7-21 1.5V • • •
GEIL GV32GB13
33C9DC
2GB
(2 x 1GB)
DS - - 9-9-9-24 1.5V • • •
GEIL GG34GB13
33C9DC
4GB
(2 x 2GB)
DS GEIL GL1L128M
88BA12N
9-9-9-24 1.3V
(low voltage)
• • •
GEIL GV34GB13
33C9DC
4GB
(2 x 2GB)
DS - - 9-9-9-24 1.5V • • •
GEIL GVP34GB
1333C7DC
4GB
(2 x 2GB)
DS - - 7-7-7-24 1.5V • • •
Hynix HMT112U6
TFR8A-H9
1GB SS Hynix H5TC1G8
3TFRH9A
- 1.35V
(low voltage)
• • •
Hynix HMT325U6
BFR8C-H9
2GB SS Hynix H5TQ2G83
BFRH9C
- - • • •
（下頁繼續）

Asus P8H77-M Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200 MHz
Supported memory module capacities	16GB, 1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA III connectors	2
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel H77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Cables included	SATA
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	2-Way CrossFireX, LucidLogix Virtu, Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x4, 1x16
LAN controller	Realtek RTL8111F
Wi-Fi standards	Not supported
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Width	245 mm
