Asus P8H77-M User Manual

1-19第一章：產品介紹
DDR3-1333MHz
供應商 型號 容量 SS/DS 芯片廠牌 芯片型號 時序 電壓
支持內存插槽
（選配）
A B C
Hynix HMT125U6
TFR8A-H9
2GB DS Hynix H5TC1G83
TFRH9A
- 1.35V
(low
voltage)
• • •
Hynix HMT351U6
BFR8C-H9
4GB DS Hynix H5TQ2G83
BFRH9C
- - • • •
KINGMAX FLFD45F-B8
KL9 NAES
1GB SS KINGMAX KKB8FNW
BFGNX-27A
- - • • •
KINGMAX FLFE85F-C8
KF9 CAES
2GB SS KINGMAX KFC8FMF
XF-DXX-15A
- - • • •
KINGMAX FLFE85F-C8
KL9 NAES
2GB SS KINGMAX KFC8FNL
XF-DXX-15A
- - • • •
KINGMAX FLFE85F-C8
KM9 NAES
2GB SS KINGMAX KFC8FNM
XF-BXX-15A
- - • • •
KINGMAX FLFE85F-B8
KL9 NEES
2GB DS KINGMAX KKB8FNWB
FGNX-26A
- - • • •
KINGMAX FLFF65F-C8
KL9 NEES
4GB DS KINGMAX KFC8FNL
XF-DXX-15A
- - • • •
KINGMAX FLFF65F-C8
KM9 NEES
4GB DS KINGMAX KFC8FNM
XF-BXX-15A
- - • • •
KINGSTON KVR1333D
3N9/1G
1GB SS ELPIDA J1108BD
BG-DJ-F
9 1.5V • • •
KINGSTON KVR1333D3
S8N9/2G
2GB SS Micron IID77 D9LGK - 1.5V • • •
KINGSTON KVR1333D3
S8N9/2G-SP
2GB SS ELPIDA J2108BC
SE-DJ-F
- 1.5V • • •
KINGSTON KVR1333
D3N9/2
2GB DS ELPIDA J1108BF
BG-DJ-F
9 1.5V • • •
KINGSTON KVR1333
D3N9/2G
2GB DS KTC D1288JPN
DPLD9U
9 1.5V • • •
KINGSTON KVR1333
D3N9/2G
2GB DS ELPIDA J1108BD
SE-DJ-F
9 1.5V • • •
KINGSTON KVR1333
D3N9/2G-SP
2GB DS KTC D1288JEM
FNGD9U
- 1.5V • • •
KINGSTON KVR1333
D3N9/2G-SP
2GB DS KINGSTON D1288JPS
FPGD9U
- 1.5V • • •
KINGSTON KHX1333C7D3
K2/4GX(XMP)
4GB
(2 x 2GB)
DS - - 7 1.65V • • •
KINGSTON KHX1333C9D3U
K2/4GX(XMP)
4GB
(2 x 2GB)
DS - - 9 XMP 1.25V • • •
KINGSTON KVR1333D
3N9/4G
4GB DS ELPIDA J2108BC
SE-DJ-F
9 1.5V • • •
KINGSTON KVR1333
D3N9/4G
4GB DS ELPIDA J2108BC
SE-DJ-F
- 1.5V • • •
KINGSTON KVR1333
D3N9/4G
4GB DS KTC D2568JE
NCNGD9U
- 1.5V • • •
KINGSTON KVR1333
D3N9/4G
4GB DS Hynix H5TQ2G
83AFR
- - • • •
KINGSTON KVR1333
D3N9/4G-SP
4GB DS KINGSTON D2568JE
NCPGD9U
- 1.5V • • •
Micron MT8JTF12864AZ-
1G4F1
1GB SS Micron 9FF22D9KPT 9 - • • •
（下頁繼續）

Asus P8H77-M Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200 MHz
Supported memory module capacities	16GB, 1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA III connectors	2
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel H77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Cables included	SATA
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	2-Way CrossFireX, LucidLogix Virtu, Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x4, 1x16
LAN controller	Realtek RTL8111F
Wi-Fi standards	Not supported
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Width	245 mm
