Asus P8H77-M User Manual

華碩 P8H77-M 主板用戶手冊1-22
DDR3-1600MHz
供應商 型號 容量 SS/DS 芯片廠牌 芯片型號 時序 電壓
支持內存插槽
（選配）
A B C
CORSAIR TR3X6G1600
C8D G(XMP)
6GB
(3 x 2GB)
DS - - 8-8-8-24 1.65V • • •
CORSAIR TR3X6G1600
C9 G(XMP)
6GB
(3 x 2GB)
DS - - 9-9-9-24 1.65V • • •
CORSAIR CMP8GX3M2A
1600C9(XMP)
8GB
(2 x 4GB)
DS - - 9-9-9-24 1.65V • • •
CORSAIR CMZ8GX3M2A
1600C7R(XMP)
8GB
(2 x 4GB)
DS - - 7-8-7-20 1.50V • • •
CORSAIR CMX8GX3M4A
1600C9(XMP)
8GB
(4 x 2GB)
DS - - 9-9-9-24 1.65V • • •
Crucial BL25664BN
1608.16FF(XMP)
6GB
(3 x 2GB)
DS - - - - • • •
G.SKILL F3-12800CL9
D-2GBNQ(XMP)
2GB
(2 x 1GB)
SS - - 9-9-9-24 1.5V • • •
G.SKILL F3-12800CL7
D-4GBRH(XMP)
4GB
(2 x 2GB)
SS - - 7-7-7-24 1.6V • • •
G.SKILL F3-12800CL7
D-4GBRM(XMP)
4GB
(2 x 2GB)
DS - - 7-8-7-24 1.6V • • •
G.SKILL F3-12800CL8
D-4GBRM(XMP)
4GB
(2 x 2GB)
DS - - 8-8-8-24 1.60V • • •
G.SKILL F3-12800CL9
D-4GBECO(XMP)
4GB
(2 x 2GB)
DS - - 9-9-9-24 XMP 1.35V • • •
G.SKILL F3-12800CL9
D-4GBRL(XMP)
4GB
(2 x 2GB)
DS - - 9-9-9-24 1.5V • • •
G.SKILL F3-12800CL9
T-6GBNQ(XMP)
6GB
(3 x 2GB)
DS - - 9-9-9-24 1.5V~1.6V • • •
G.SKILL F3-12800CL7
D-8GBRH(XMP)
8GB
(2 x 4GB)
DS - - 7-8-7-24 1.6V • • •
G.SKILL F3-12800CL8
D-8GBECO(XMP)
8GB
(2 x 4GB)
DS - - 8-8-8-24 XMP 1.35V • • •
G.SKILL F3-12800CL9
D-8GBRL(XMP)
8GB
(2 x 4GB)
DS - - 9-9-9-24 1.5V • • •
GEIL GET316GB1600
C9QC(XMP)
16GB
(4x 4GB )
DS - - 9-9-9-28 1.6V • • •
GEIL GV34GB1600
C8DC(XMP)
2GB DS - - 8-8-8-28 1.6V • • •
KINGMAX FLGE85F-B8KJ9
A FEIS(XMP)
2GB DS - - - - • • •
KINGMAX FLGE85F-B8MF7
MEEH(XMP)
2GB DS - - 7 - • • •
KINGSTON KHX1600C9D3
P1K2/4G
4GB
(2 x 2GB)
SS - - - 1.5V • • •
KINGSTON KHX1600C9D3
K3/12GX(XMP)
12GB
(3x4GB)
DS - - 9-9-9-27 1.65V • • •
KINGSTON KHX1600C9D3T1
BK3/12GX(XMP)
12GB
(3x4GB)
DS - - 9-9-9-27 1.65V • • •
KINGSTON KHX1600C9D3K4/
16GX(XMP)
16GB (
4GB x4 )
DS - - - 1.65V • • •
KINGSTON KHX1600C9AD3/
2G
2GB DS - - - 1.65V • • •
（下頁繼續）

Asus P8H77-M Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200 MHz
Supported memory module capacities	16GB, 1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA III connectors	2
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel H77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Cables included	SATA
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	2-Way CrossFireX, LucidLogix Virtu, Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x4, 1x16
LAN controller	Realtek RTL8111F
Wi-Fi standards	Not supported
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Width	245 mm
