Asus P8H77-M User Manual

1-23第一章：產品介紹
DDR3-1600MHz
供應商 型號 容量 SS/DS 芯片廠牌 芯片型號 時序 電壓
支持內存插槽
（選配）
A B C
KINGSTON KVR1600D3
N11/2G-ES
2GB DS KTC D1288JPN
DPLD9U
11-11-
11-28
1.35V-1.5V • • •
KINGSTON KHX1600C7D3
K2/4GX(XMP)
4GB
( 2x 2GB )
DS - - - 1.65V • • •
KINGSTON KHX1600C8D3
K2/4GX(XMP)
4GB
(2 x 2GB)
DS - - 8 1.65V • • •
KINGSTON KHX1600C8D3T1
K2/4GX(XMP)
4GB
(2 x 2GB)
DS - - 8 1.65V • • •
KINGSTON KHX1600C9D3
K2/4GX(XMP)
4GB
(2 x 2GB)
DS - - 9 1.65V • • •
KINGSTON KHX1600C9D3L
K2/4GX(XMP)
4GB
(2 x 2GB)
DS - - 9 XMP 1.35V • • •
KINGSTON KHX1600C9D3X2
K2/4GX(XMP)
4GB
(2 x 2GB)
DS - - 9-9-9-27 1.65V • • •
KINGSTON KHX1600C9D3T1
K3/6GX(XMP)
6GB
( 3x 2GB )
DS - - - 1.65V • • •
KINGSTON KHX1600C9D3
K3/6GX(XMP)
6GB
(3 x 2GB)
DS - - 9 1.65V • • •
KINGSTON KHX1600C9D3T1B
K3/6GX(XMP)
6GB
(3 x 2GB)
DS - - 9-9-9-27 1.65V • • •
KINGSTON KHX1600C9D3
K2/8GX(XMP)
8GB
(2 x 4GB)
DS - - 9-9-9-27 1.65V • • •
KINGSTON KHX1600C9D
3P1K2/8G
8GB
(2 x 4GB)
DS - - - 1.5V • • •
Transcend JM1600KLN-8GK 8GB
(2 x 4GB)
DS Transcend TK483PCW3 - - • • •
Asint SLZ3128M
8-EGJ1D(XMP)
2GB DS Asint 3128M8-GJ1D 9-9-9-24 1.6V • • •
Asint SLA302G0
8-EGG1C(XMP)
4GB DS Asint 302G08-GG1C - - • • •
Asint SLA302G0
8-EGJ1C(XMP)
4GB DS Asint 302G08-GJ1C - - • • •
Elixir M2P2G64CB8
HC9N-DG(XMP)
2GB DS - - - - • • •
Mushkin 998659(XMP) 6GB
(3 x 2GB)
DS - - 9-9-9-24 - • • •
Mushkin 998659(XMP) 6GB
(3 x 2GB)
DS - - 9-9-9-24 1.5~1.6V • • •
PATRIOT PGS34G1600LLKA 4GB
(2 x 2GB)
DS - - 7-7-7-20 1.7V • • •
SanMax SMD-4G68HP-16KZ 4GB DS HYNIX H5TQ2G83
BFR PBC
- - • • •

Asus P8H77-M Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200 MHz
Supported memory module capacities	16GB, 1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA III connectors	2
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel H77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Cables included	SATA
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	2-Way CrossFireX, LucidLogix Virtu, Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x4, 1x16
LAN controller	Realtek RTL8111F
Wi-Fi standards	Not supported
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Width	245 mm
