4.2.5 RADIUS Setting
RADIUS (Remote Authentication Dial In User Service) Setting
provides an extra layer of security when you choose WPA-
Enterprise, WPA2-Enterprise, or Radius with 802.1x as your
Authentication Mode.
To set up wireless RADIUS settings:
1. Ensure that the wireless router’s authentication mode is set to
WPA-Enterprise or WPA2-Enterprise.
NOTE: Please refer to section 4.2.1 General for confi guring your
wireless router’s Authentication Mode.
2. From the navigation panel, go to Advanced Settings >
Wireless > RADIUS Setting.
3. Select the frequency band.
4. In the Server IP Address fi eld, key in your RADIUS server’s IP
Address.
5. In the Server Port fi eld, key in the server port.
6. In the Connection Secret fi eld, assign the password to access
your RADIUS server.
7. Click Apply.
