Hydraulic Drive Circuit
Figure 3-3 PT-70/80 Hydraulic Drive Circuit
3-3
Rubber Track Loader
3. Circuit Diagrams
DRIVE MOTOR
DRIVE MOTOR
DRIVE PUMP
DRIVE CONTROL
TO COOLER
TANK
CASE DRAIN
BRAKE
2-SPEED SHIFT (PT-80)
DRIVE PRESSURE
RELIEF VALVES (4)
5500 PSI
