Lift Arm Control Valve
Figure 3-4 PT-70/80 Lift Arm Control Valve
3-4
Rubber Track Loader
3. Circuit Diagrams
RELIEF VAL
VE SETTINGS
(B3) 3307 PSI
(B2) 3147 PSI
(B1) 3640 PSI
(A3) 3307 PSI
(A2) 3669 PSI
(A1) Anti-Cavitation
Check Valve
