Chapter Overview
This chapter provides procedures for the removal and
installation of the engine and associated components.
Personal Safety
Improper or incomplete maintenance/repair of a Rubber
Track Loader can be dangerous and may result in
machine damage, injury or even death.
Do not attempt to perform any type of repair or mainte-
nance on a Rubber Track Loader until you have read and
fully understood the information in this manual.
Refer to the Operation and Maintenance manual for
instructions regarding proper machine operation tech-
niques before operating any Rubber Track Loader.
Prior to performing any type of service work on a
Rubber Track Loader, read and understand Chapter 1
(Product Safety) for personal safety information.
Removal and Installation
Removal and installation procedures are provided for
the following engine related components.
• Battery
• Exhaust
• Air Cleaner
• Engine
Note: Procedures are provided for only those engine associ-
ated components listed above. However, exploded parts dia-
grams exist in the PT-70 and PT-80 parts manuals to serve
as visual aids in the assembly and disassembly of other sys-
tem components.
Battery
Removal
1. Open the hood at the rear of the machine.
2. Disconnect the negative and positive battery
cables from the battery terminals. (fig. 12-1)
3. Remove the wingnuts securing the battery hold
down strap. (fig. 12-2)
12. Engine
12-1
12-1
!WARNING!
12-2
