ASV RT-75 - 3.6 Transmission; 3.7 Auxiliary Hydraulics; 3.8 Ground Pressure; 3.9 Operating Specs.

3.6 Transmission RT-75 RT-75 HD
3.7 Auxiliary Hydraulics RT-75 RT-75 HD
3.8 Ground pressure RT-75 RT-75 HD
3.9 Operating Specs. RT-75 RT-75 HD
Note: The Maximum Gross Vehicle Weight of the RT-75 / RT-75HD is not to
exceed 12650 lb (5738 kg.). This includes an operator, accessories, attachments
and material being carried. * Tipping load and operating capacity are measured
using a foundry bucket.
3.10 Refill Capacities (approx.) RT-75 RT-75 HD
Make
Rexroth Rexroth
Type
A22VG045 A22VG045
Design
Axial piston Axial piston
Displacement
2.75 in.³ (45 cc) / rev. 2.75 in.³ (45 cc) / rev.
Relief Pressure
5500 psi (37,920 kPa) 5500 psi (37,920 kPa)
Make
Turolla Turolla
Type
DE2R DE2R
Design
Gear Gear
Displacement (Main/low)
1.94 in. ³ (31.8 cc) /rev. 1.94 in. ³ (31.8 cc) /rev.
Displacement (High flow)
1.16 in. ³ (19 cc) /rev. 1.16 in. ³ (19 cc) /rev.
Relief pressure
3300 psi (22,750 kPa) 3300 psi (22,750 kPa)
Low Flow @2500 RPM
0-22.6 gpm (0-85.6 lpm) 0-22.6 gpm (0-85.6 lpm)
High Flow @2500 RPM
35.7 gpm ( 135.1 lpm) 35.7 gpm ( 135.1 lpm)
At operating weight
3.5 psi (24.1 kPa) 3.6 psi (24.8 kPa)
Tipping load *
7857 lb (3564 kg) 8000 lb (3629 kg)
Operating capacity 50% *
3929 lb (1782kg) 4000 lb (1814 kg)
O
p
eratin
g
ca
p
acit
y
35% *
2750 lb (1247 k
g
) 2800 lb (1270 k
g
)
Fuel tank
18.4gal(69.65l) 18.4gal(69.65l)
Hydraulic tank
8gal(30.3l) 8gal(30.3l)
Engine coolant
5.5gal(20.8l) 5.5gal(20.8l)
Engine oil including filter
9qt.(8.52l) 9qt.(8.52l)
33
3 TECHNICAL DATA
RT-75 / RT-75HD US O&M
0405-073 2020-07
