4 MACHINE DESCRIPTION / CONTROLS
43
RT-75 / RT-75HD US O&M
0405-073 2020-07
4.6 Two Speed
The RT-75 / RT-75HD is equipped with a two-speed drive system. Low range is
best suited to performing strenuous work or operating attachments. High range is
intended mainly for transporting.
To shift between high and low ranges, push the button on the front of the left
joystick. When shifting between ranges, slow the machine to ensure a smooth
transition. The high range indicator (rabbit icon) illuminates to confirm high range
operation.
Note: If the machine is turned off, the lap bar is raised, or the operator exits the
seat, the machine automatically returns to low range.
4.7 Bucket Positioning (optional)
RT-75 / RT-75HD machines can be equipped
with feature commonly referred to as “bucket
positioning”. The bucket positioning system
does not automatically level your attachment.
Instead, it will maintain the current angle of
the quick attach (relative to level) throughout
the upward cycle of the lift arms.
The bucket positioning feature can be turned on or off with the switch located on
the right switch panel (item 1, figure 4.7-1).
Note: The bucket positioning function can be overridden by operating the curl or
dump functions of the appropriate joystick.
4.7-1
1
