Atag XL75W - Page 97

97
(Reserved) --
(Reserved) --
(Reserved) --
(Reserved) --
Flow Sensor Open Short Circuit 110 1
Flow Sensor Open Short Circuit 110 2
Return Sensor Open Short Circuit 112 1
Return Sensor Open Short Circuit 112 2
Sensors Check 118 1
Sensors Check 118 2
Flow Check 1 (or 3 or 4) Three Times 103 1
Flow Check 1 (or 3 or 4) Three Times 103 2
Flow Check 3 (or 1 or 4) Three Times 105 1
Flow Check 3 (or 1 or 4) Three Times 105 2
Flow Check 4 (or 1 or 3) Three Times 106 1
Flow Check 4 (or 1 or 3) Three Times 106 2
(Reserved) --
(Reserved) --
Gas Relais check Failed 309 1
Gas Relais check Failed 309 2
Pump Feedback Open Short Circuit 142 1
Pump Feedback Open Short Circuit 142 2
PCB Fault 1 303 1
PCB Fault 1 303 2
Too many Reset 304 1
Too many Reset 304 2
Pump Feedback Abnormal Running 143 1
Pump Feedback Abnormal Running 143 2
PCB Fault 2 306 1
PCB Fault 2 306 2
Pump Feedback Abnormal Stopped 144 1
Pump Feedback Abnormal Stopped 144 2
No Flame detection (3 attempts) 501 1
No Flame detection (3 attempts) 501 2
False Flame 502 1
False Flame 502 2
Flame lift (3 attempts) 504 1
Flame lift (3 attempts) 504 2
No Flame 1 5P1 1
No Flame 1 5P1 2
Errors
(UURUFRGHVDQGIDXOW¿QGLQJ
Message on display (no indication of BHE0 and BHE1
Fault Code
engine 1
Fault Code
engine 2
(if applicable)
