18. Consumable Parts and Optional Items
(1) Consumable Parts
The following consumable parts are available for the instrument.
These items should be monitored and replaced as necessary. To place an order, please contact
an Authorized ATAGO Distributor.
Part name Part number Description
Tie band RE-8507 Maximum temperature: Max. 150℃
Quantity: 10 pieces
For water bath connection
O-ring (Viton) RE-68002
O-ring (EPDM) RE-68115
O-ring (Viton) RE-68002
O-ring used to connect the sample inlet unit to the prism stage
unit of the instrument.
(2) Optional Items
The following optional items are available for the instrument.
These items can be ordered through an Authorized ATAGO Distributor.
C "3.Unpacking and Installation" page 9
Product or part name
Catalog or
part number
Description
AC adapter AD-32 Cat.No.3527 Converts the AC 100V to the DC24V and supplies the power
to the instrument.
AC adapter AD-33 Cat.No.3528 Converts the AC 110V to the DC24V and supplies the power
to the instrument.
AC adapter AD-34 Cat.No.3529 Converts the AC 220-240V to the DC24V and supplies the
power to the instrument.
Hose connector RE-67501 Outside diameter of the Hose connector: 12mm φ
Compression
Fitting
RE-67503 Compression fitting 10mmφ
RE-67511 1S
RE-67512 1.5S
Straight type
IDF/ISO clamp
union (ferrule)
RE-67521 2S
Straight type
IDF/ISO screw
union (screw)
RE-67523 2S
RE-67515 25A Straight type
JIS Flange
RE-67525 40A
RE-67611 1S
Sample
inlet
unit
L type
IDF/ISO clamp
union (ferrule)
RE-67621 2S
RE-65374 4-pin connector, one-sided crimp contact (5m)
RE-65375 4-pin connector, one-sided crimp contact (10m)
RE-65376 4-pin connector, one-sided crimp contact (15m)
RE-65377 4-pin connector, one-sided crimp contact (20m)
Recorder output cable
RE-65378 4-pin connector, one-sided crimp contact
(Optional length)
RE-5647 4-pin connector, one-sided D-SUB 25-pin connector
* Please specify the length (1 to 15m) upon ordering.
RS-232C cable
D-SUB 25-pin
RE-5677 4-pin connector, one-sided D-SUB 25-pin connector (15m)
RE-65331 4-pin connector, one-sided D-SUB 9-pin connector
* Please specify the length (1 to 15m) upon ordering.
RS-232C cable
D-SUB 9-pin
RE-65330 4-pin connector, one-sided D-SUB 9-pin connector (15m)
Stand RE-8607 Stand for mounting the instrument and the AD-32 (AD-33 or
AD-34).
