24
9. Power Supply
WARNING
◇ NEVER connect the instrument to power other than DC24V (allowable
fluctuation is ±10%).
◇ NEVER insert the plug of the AD-32 (AD-33 or AD-34) AC Adapter to
an outlet other than AC 100-240V.
◇ NEVER use a power cable that is damaged, cut, broken, or altered. Fire,
electrical shock or burns may occur.
To purchase replacement power cables, contact an Authorized ATAGO
Distributor.
CAUTION
◇ NEVER plug the AD-32 (AD-33 or AD-34) AC Adapter in with wet
hands.
◇ When disconnecting the power cable from an AC 100-240V outlet, be
sure to remove by pulling the plug.
Pulling by the cable may damage the cable and cause fire or electrical
shock.
◇ When connecting the AC Adapter AD-32 (AD-33 or AD-34) to an
outlet, be sure to connect the ground pin.
m The instrument has no power switch. When power is supplied to the instrument, the
measurement value display illuminates and the DMF(%) measurement commences.
(1) When the instrument is used alone
① Confirm that the power (DC24V) input cable is properly connected to the instrument and
the DC24V power supply.
② When the DC24V power is supplied, the instrument turns on and the measurement value
display will illuminate.
(2) When the AC adapter AD-32, AD-33 or AD-34 (optional) is used
① Confirm that the instrument and the AD-32 (AD-33 or AD-34) are properly connected.
② When the AD-32 (AD-33 or AD-34) power cable is plugged into an outlet, the instrument
turns on and the measurement value display will illuminate.
When the AD-32 (AD-33 or AD-34) is connected to an outlet and the DC24V is output, a
lamp will illuminate on the bottom of the AC Adapter.
To Next Page
