Installing the MERLIN Identifier System
Wall Mounting
To mount the MERLIN Identifier Display unit to the wall, follow the
instructions below:
1.
2.
3.
4.
Position the wall mounting bracket on the wall near the
MERLIN telephone and an AC power outlet, and mark
points for the pilot holes.
Remove the wall mounting bracket, drill pilot holes, and
install the plastic screw anchors.
Reposition the wall mounting bracket over screw anchors
and drive the #6 x 1/2-inch self-tapping screws through the
mounting holes and into the anchors.
Align the slots on the back of the MERLIN Identifer Display
with the three prongs on the wall mounting bracket, and
snap the MERLIN Identifier Display into place.
Telephone Mounting
To mount the MERLIN Identifier Display unit to a MERLIN
telephone, follow the manufacturer’s instructions included with the
telephone mounting bracket.
16
STEP 4:
Mount the MERLIN Identifier Display Units
