Parts Reference
B
The following tables show the parts included with each MERLIN
®
Identifier system component package.
Controller Assembly with Administrative Display and Keyboard
PE Code 6128 KBD COM Code 406 891 556
Parts Name
Quantity
Controller
1 (with mounting plate)
#6 x 1/2" Self-Tapping Screws
3 (for mounting Controller)
Cable phone 8-conductor x 7'
4 (Controller to MERLIN)
Cable phone 4-conductor x 7'
4 (Controller to MERLIN CO lines)
Power Adapter 9V 2.5mm plug
1 (9 Volt 1 Amp plug—Black)
Controller Cable Cover
1
Keyboard 101
1
Keyboard Mounting Brackets
2
Keyboard Cord Adapter
1
Cable phone 8-conductor x 7'
1 (Controller to Admin. Display)
#6 x 1/2" Self-Tapping Screws
6 (for mounting keyboard)
Display Assembly
1 (with wall mounting)
Documentation
3
Parts Reference
55
To Next Page
