Parts Reference
Controller Assembly with PC Administration
PE Code 6128 PCA COM Code 406 891 564
Parts Name
Quantity
Controller
1 (with mounting plate)
#6 x 1/2" Self-Tapping Screws
3 (for mounting Controller)
Cable phone 8-conductor x 7'
4 (Controller to MERLIN)
Cable phone 4-conductor x 7'
6 (Controller to MERLIN CO
lines) and RS232 connections
Power Adapter 9V 2.5mm plug
1 (9 Volt 1 Amp plug—Black)
Controller Cable Cover
1
Adapter (Serial Port @ Controller)
1
Adapter (Serial Port @ PC DB25)
1
Adapter (Serial Port @ PC DB9)
1
Documentation
2
Display Assembly with Mounting Bracket
PE Code 6128 DIS COM Code 406 891 572
Parts Name
Quantity
Display Unit
1
Power Adapter
1 (9 Volt 200ma plug—Black)
Cable phone 8-conductor x 18"
1 (Display to phone)
Cable phone 4-conductor x 7'
1 (RS232 port to PC)
Adapter (DB9 to 4-conductor
1 (Converter DB9 port to phone
phone)
connector)
Mounting Bracket
1
#6 x 1/2" Self-Tapping Screws
2
and wall anchors
Documentation
1
56
Parts Reference
