Atari 800 Service Manual

ATARI Personal Computers 6-1
Description Part No. Quantity
C omponents - Integrated Circuits (Cont.)
74LS244 CO14313 4
74LS158 CO14345 4
74LS00 CO14341 4
74LS09 CO14341 4
Transistor Array CO10174 4
74LS243 CO14347 4
74LS32 CO14362 4
Components - Other
Operators Manual 800 CO14769 2
Operators Manual 400 CO14768 2
Keyboard 800 CAO12952-01 1
Keyboard 400 CAO14031 1
RF Cable CAO14851 5
Speaker Assembly CAO11840 4
Power Adapter CAO14748 2
C rystal 3.579575 CO10177 2
Switch, Interlock CO14387 10
Voitage Regulator (5V) CO14349 5
Voltage Regulator (12V) CO14348 5
Module RF ' B' CAO12174 5
400 Miscellaneous Parts Kit
800 Miscellaneous Parts 1
410 Program Cassette Recorder 2
Diagnostic Test
Stand Alone Test Cartridge TE15644 1
Serial Port Jumper Assembly TE15639 1
Controller Port Jumper Assembly TE15638 1
Supplies
Board Cleaning Brush 1
Aud Brush 1
Lubriplate DS-ES 1
Dust Free Cloth 1
Torque Seal 1
6-2 System Service Manual

Atari 800 Specifications

General

Processor	MOS Technology 6502
Processor Speed	1.79 MHz
ROM	10 KB
Graphics	ANTIC and GTIA chips
Release Year	1979
Display Resolution	up to 320 x 192
Colors	128 colors
Sound	4 channels
Storage	Cartridge, cassette, floppy disk
Ports	Cartridge, serial, monitor
Operating System	Atari OS
