21
Chapter 4
Keyboard Port Operation
The CS1642A / CS1644A provides an extensive, easy-to-use, hotkey function
that makes it convenient to control and configure your KVM installation from
the keyboard. Hotkeys provide asynchronous (independent) switching of the
KVM, USB hub and audio focus. If you wish, you can give one computer the
KVM console focus, another the USB hub focus and the other two the audio
focus.
Port Switching
All port switches begin with tapping the Scroll Lock key twice. The tables
below describe the actions that each combination performs.
Note: If using the Scroll Lock key conflicts with other programs running on
the computer, the Ctrl key can be used, instead. See Alternate Port
Switching Keys, page 25, for details.
Cycling Through the Ports
Hotkey Action
[Scroll Lock] [Scroll Lock]
[Enter]
Brings the KVM, USB hub, and audio focus from the
port that currently has the KVM focus to the next port on
the installation (1 to 2; 2 to 1 for the CS1644
A: 1 to 2; 2
to 3; 3 to 4; 4 to 1 for the CS1644
A).
[Scroll Lock] [Scroll Lock]
[K] [Enter]
Brings only the KVM focus from the port that currently
has it to the next port on the installation. The USB and
audio focus remain where they are.
[Scroll Lock] [Scroll Lock]
[U] [Enter]
Brings only the USB hub focus from the port that
currently has it to the next port on the installation. The
KVM and audio focus remain where they are.
[Scroll Lock] [Scroll Lock]
[S] [Enter]
Brings only the audio focus from the port that currently
has it to the next port on the installation. The KVM and
USB hub focus remain where they are.
